WEIDIAN Opnsense Firewall Mini PC Home Network Firewall Micro Firewall Appliance, 4 x 2.5g NIC LAN Port Celeron J4125 Windows 10 Pro Small Fanless PC 16GB RAM 512GB SSD, AES-NI 6*USB COM HD SIM Slot

Price: $650.64
(as of Mar 19, 2024 04:08:42 UTC – Details)

Product Description

4 x 2.5Gbe Ethernet Network Security Firewall Mini PC

CPU Celeron J4125, 2.0 GHz, 4 MB cache, up to 2.70 GHz # of Cores 4 # of Threads 4 Output 1 x HD Output Graphics UHD Graphics 600 Memory (RAM) 1 x 260 Pin DDR4 SO-DIMM Socket, Max 32GB RAM, 2400Mhz Storage Support 1 x msata SSD, 1 x SATA 3.0 slot for 2.5” HDD /SSD WiFi With dual band antenna+BT 4.0 I/O Port 4 x 2.5g RJ45 Lan, 2 x USB 3.0 port, 4 x USB 2.0 port, 1 x HD port, 1 x RS232 Com port Language Default English language (you can set your favorite language.) Material Aluminum housing Noise Fanless System Operating Environment -20 ~ 60 Centigrade (-68F~140F) Humidity 10%~85%(non-condensing) Operating System Preinstall Windows 10 Pro as defaulted Size 13.5*12.7*3.9cm / 5.31*5.00*1.54 inch

2500Mbps LAN Fanless Firewall Micro Appliance Router Firewall Mini PC

This H3 Model Home Network Firewall PC is the latest ultra-compact PC measuring 13.5cm x 12.7cm x 3.9CM so small in fact that it could fit in your pocket! This Fanless Mini PC is powered by a quad core celeron J4125.Featured with HD port, WEIDAIN Mini PC can be connected to one monitor with 4K HD for visually home entertainment, perfect for home office, Internet surfing, watching movies, or simply browsing the web.This Industrial Firewall PC can be used as a virtual private network and network firewall and applied to various scenarios such as corporate offices, soft routing, hotels/restaurants, industrial areas, shopping malls, schools etc.

WEIDIAN Mini Desktop PC Super Small Computer Highlights

This mini pc has quad cores Celeron J4125 processor with 4M Cache, 4 Cores 4 Threads, Base Frequency 2.00 GHz Burst Frequency 2.70 GHz)It’s WEIDIAN Mini PC, which is small and weighs only 0.60kg , so you can put it wherever you want.With the fanless design, this micro pc pretty silent when it working.This small body comes with big memory capacity, DDR4 memory slot up to 32GB RAM, and it supports SATA3.0 for 2.5 inch HDD/SSD ,msata SSD and masta SSD, preinstalled Windows 10 Pro in the SSD for file saving, get fast speed and huge capacity.

Fanless Mini PC 4 NIC 2.5G Ports

Windows 10 Pro Firewall Appliance PC

Small Powerful J4125 Mini PC

4K HD Display Mini Computer

Industrial fanless mini pc firewall appliance hardware

2.4GHz/5GHz Dual Band Wi-Fi

2.4GHz /5GHz dual band wifi offers fast ans stable speed, makes the wireless device more power-saving, and meets the big data wireless transmission needs.

Large Expandable Storage

You can expand the storage with a SATA slot up to 2 TB and a mSTA slot up to 1TB. High-Speed Performance 2500Mbps LAN, Stable Wired Access, Make Everything Smoother Whenever Transmission and Download.

Celeron J4125 Processoer

WEIDIAN Mini desktop PC is paired with a Celeron Generation processor, and plethora of premium connectivity. Work on the demanding creative workload, boost your productivity, and power through the workflow in the most compact form factor.

Important Q&A

Q1: How long do you provide the service when any problem with this mini desktop pc ?A1: We provide 3 year quality protection and lifetime online support.Q2: How to enter the BIOS?A2: You can enter BIOS by repeat and fast pressing “Delete” when reboot.Q3: Have problems with OS activation/update?A3: Please let me know through Amazon’s order details, we will try the best to help you.Q4: There is nothing on monitor , what can I do ?A4: When using WEIDIAN mini pc and find all indicator shows correct, RAM also correctly plugged in, but totally no display, it may due to the CMOS problem, it remember some errow and shows nothing on hardware, you will need to remove your CMOS battery and start the pc again.

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.6 out of 5 stars
109

4.8 out of 5 stars
7

4.8 out of 5 stars
5

4.5 out of 5 stars
17

4.6 out of 5 stars
40

4.7 out of 5 stars
8

Price

$412.64$412.64

$537.00$537.00

$823.00$823.00

$751.00$751.00

$676.00$676.00

$1,076.00$1,076.00

Operating System
Windows 11 Pro Windows 11 Pro Windows 11 Pro Windows 11 Pro Windows 11 Pro Windows 11 Pro

GPU
UHD Graphics 600 HD Graphics 620 UHD Graphics UHD Graphics 620 AMD Radeon Graphics GEFORCE GTX 1650 4GB GDDR5

RAM
Single Channel DDR4 (max 32G RAM) Single channel DDR4 (max 32G) Dual Channel DDR4 (max 64G RAM) Dual Channel DDR4 (max 64G) Dual Channel DDR4 (max 64G) Dual Channel DDR4 (max 64G)

Hard Disk
Support 1 x msata SSD, 1 x M.2 NVME SSD ( PCIE3.0 x 2 ), 1 x SATA 3.0 slot for 2.5” HDD /SSD Support 1 x M.2 SSD (M.2 2280 SATA / NVME SSD PCIE 3.0 x 4) and 1 x SATA 3.0 slot for 2.5” HDD /SSD Support 1 X M.2 SATA SSD or NVME SSD + 1 x SATA3.0 for 2.5 inch HDD/SSD Support 1 x M.2 KEY M for SATA&PCIE3.0 (M.2 2280, NVME) + 1 x mSATA slot + 1 x SATA3.0 for 2.5 inch HDD/SSD Support 2 x M.2 2280 SSD slots; 1 x SATA3.0 (support 2.5 inch hard disk, Max 2TB HDD); Support 1 x M.2 2280/ NVME SSD + 1 x SATA3.0 for 2.5 inch HDD/SSD

Output
VGA+HD 2HD 2HD+DP HD+DP+EDP DP+HD+USB-C HD(4K 60Hz)+ DP(8K 60Hz)+ DVI

USB Ports
2 x USB3.0 + 2 x USB2.0 4 x USB3.0 + 4 x USB2.0 4 x USB3.0 + 2 x USB2.0 4 x USB3.0 + 4 x USB2.0 3 x USB3.0 + 4 x USB2.0 4 x USB3.0 + 4 x USB2.0

Com Ports
2 x RS232 COM port 2 x RS232 COM port 2 x RS232/485 COM port; GPIO port 6 x RS232 COM port No No

Size
13.6 x 12.6 x 4.3CM ‎16.99 x 12.6 x 5.79 CM New 22.0 x 12.7 x 6.0 CM 23.7 x 17.5 x 5.3CM 19.2 x 13.0 x 5.0CM 27.7 x 20.1 x 5.6CM

Built-in Fan
No No No No
✓

✓

4 x 2.5g LAN Mini Firewall PC ➥ This Fanless PC is equipped with 4 x RJ45 I225-V GbE LAN ports, making it an excellent choice for a firewall solution. It comes preinstalled with Windows 10 Pro and supports popular open-source software solutions like Linux, CentOS, OPNsense, ESXi etc. With the ability to reinstall open-source systems, this Network Firewall Computer can be easily configured as a firewall, LAN router, VPN appliance, smart gateway, or edge computing terminal.
4G WiFi Network Firewall Applicance ➥ J4125 Mini industrial PC features a SIM slot on the motherboard, allowing you to enjoy a 4G WiFi network and access the Internet from anywhere (4G module and SIM card not included). This 4G network provides high-speed Internet access, making it ideal for applications such as home multimedia, wireless network usage, and places with a network. Experience faster Internet speeds and enhance your online experience with this 4G-enabled Firewall Opnsense Mini PC.
Powerful Home Network Firewall PC ➥ Designed as a security gateway appliance, this 2.5GbE NIC PC is perfect for home use, branch offices, or remote offices. With its soft routing+switch+AP multi-function capability, it supports features like QoS and ad blocking, making it an advanced firewall PC. It can easily handle networks with 10-50 users, ensuring faster access speeds for important network PCs, key servers, and crucial users. Protect your network with this powerful and versatile Mini PC.
Portable & Cooling Fanless PC ➥ This Mini PC is not only powerful but also portable. With dimensions of 13.5*12.7*3.9cm and a net weight of 0.6kg, it is convenient to carry anywhere. Firewall Micro Appliance’s compact size saves valuable space, making it suitable for various environments. The fanless cooling design, along with its aluminum housing, ensures excellent robustness and efficient heat dissipation. Enjoy the benefits of a high-performance Mini PC without any noise or heat issues.
Components & Compatibility ➥ The WEIDIAN Firewall Appliance 2.5gbe Small PC is equipped with DDR4 RAM slot(max 32G), 1 x mSATA slot, 1 x SATA3.0 HDD/SSD, 1 x HD port, 2 x USB 3.0, 4 x USB 2.0, 1 x RS232 Com, 4 x 2.5Gbe RJ45 Lan. This Firewall Home PC provides versatile connectivity options. Additionally, it supports convenient features like Auto Power On, Wake on LAN, Watch Dog and PXE. Rest assured, our WEIDIAN Mini PCs are FCC, RoHS, and CE certified and come with lifetime tech support.
